Fuji 6D120A-050 New IGBT Module

#Fuji, #6D120A_050, #IGBT_Module, #IGBT, 6D120A-050 300A/600V/1200W 2 in one package;

· Categories: IGBT Module
· Manufacturer: Fuji
· Price: US$
· Date Code: 2021+
. Available Qty: 600
Like
Tweet
Pin It
4k
Email: sales@shunlongwei.com
Whatsapp: 0086 189 2465 1869
-- OR --

Request For Price Now !

6D120A-050 Specification

Sell 6D120A-050, #Fuji #6D120A-050 New Stock, 6D120A-050 300A/600V/1200W 2 in one package;, #IGBT_Module, #IGBT, #6D120A_050
Email: sales@shunlongwei.com
URL: https://www.slw-ele.com/6d120a-050.html

the Fuji 6D120A-050 power semiconductor device.

Features:

  • Low VCE(sat): The device exhibits low saturation voltage, reducing power losses during operation.
  • Compact package: The device is available in a compact package, making it suitable for space-constrained applications.
  • P.C. board mount: The device can be mounted on a printed circuit board (PCB) for ease of integration.
  • Converter diode bridge, Dynamic brake circuit: The device can be utilized in applications involving diode bridges and dynamic brake circuits.

Applications:

  • Inverter for motor drive: The device can be used as an inverter in motor drive applications.
  • AC and DC servo drive amplifier: It's suitable for both AC and DC servo drive amplifier circuits.
  • Uninterruptible power supply: The device can be integrated into uninterruptible power supply (UPS) systems.

Maximum Ratings (Tc=25°C unless otherwise specified):

  • Collector-Emitter voltage (Vces): 600V
  • Gate-Emitter voltage (VGES): ±20V
  • Collector current (Ic): 300A
  • Collector current (Icp): 600A (presumably for pulse conditions)
  • Collector power dissipation (Pc): 1200W
  • Collector-Emitter voltage (VCES): 2500V
  • Operating junction temperature (Tj): +150°C
  • Storage temperature (Tstg): -40 to +125°C
