LTA084A380F: 8.4-inch VGA TFT-LCD Engineered for Longevity and Serviceability in Industrial Systems
Introduction and Key Features
Engineered for Enduring Performance in Demanding Environments
The LTA084A380F is an 8.4-inch a-Si TFT-LCD module designed for robust, long-term performance in industrial applications. It delivers proven reliability, highlighted by a 50,000-hour backlight MTTF and a service-friendly replaceable lamp unit, directly addressing total cost of ownership concerns. Key specifications include a 640x480 VGA resolution, 300 cd/m² brightness, and a wide operational temperature range. This display is engineered to provide a stable and maintainable visualization solution for HMIs, control panels, and instrumentation where operational uptime is critical. For systems requiring a similar form factor but with different interface or optical characteristics, the G084SN05 V9 offers alternative specifications for design consideration.
Key Parameter Overview
Specifications and Value Interpretation for System Integration
The technical specifications of the LTA084A380F are foundational to its reliable performance in industrial environments. Each parameter is selected to ensure consistent operation and straightforward integration into a variety of machine and process control systems.
| Parameter | Specification | Engineering Value & Interpretation |
|---|---|---|
| Screen Size | 8.4 inches | Provides a compact yet clear viewing area suitable for operator panels and embedded systems where space is a consideration. |
| Resolution | 640(RGB)×480 [VGA] | Offers standard VGA resolution, ensuring compatibility with a vast range of industrial controllers and single-board computers without needing complex scaling. |
| Brightness | 300 cd/m² (Typ.) | Delivers sufficient luminance for clear readability in typical indoor industrial and factory floor environments. |
| Backlight Technology | 1 pcs CCFL, 50K hours MTTF, Replaceable | The high Mean Time To Failure (MTTF) of 50,000 hours signifies a long operational life. Think of it as running continuously for over 5.7 years. The key value here is its replaceability, which allows for field servicing to extend the product's total lifecycle, a crucial factor in fixed-installation industrial equipment. |
| Operating Temperature | -10 ~ 70 °C | This wide range ensures the display can function reliably in unconditioned environments, from cold-start factory floors to enclosures with significant heat buildup from other components. |
| Storage Temperature | -20 ~ 80 °C | Guarantees panel integrity and resilience during transport and warehousing in extreme climates, reducing the risk of component failure before installation. |
| Signal Interface | Parallel RGB (1 ch, 6-bit) | A standard, straightforward interface that simplifies integration with legacy and embedded systems, reducing the need for specialized interface converters. |
| Weight | 440g (Typ.) | The moderate weight contributes to manageable mechanical design for enclosures and mounting arms without requiring overly heavy-duty structural support. |
For a comprehensive list of electrical characteristics and timing diagrams, please Download the LTA084A380F datasheet for detailed specifications and performance curves.
Application Scenarios & Value
Delivering System-Level Benefits in Industrial HMI and Control
The LTA084A380F is best suited for applications where long-term availability and serviceability are paramount. Its design directly addresses the challenges faced by engineers deploying human-machine interfaces (HMIs), process control terminals, and specialized instrumentation. What is the primary benefit of its replaceable backlight? It allows for cost-effective field maintenance, extending the operational life of the entire host system and avoiding expensive, complete HMI replacements. This feature is particularly valuable in fixed installations like factory automation lines or building management systems where equipment lifecycles are measured in decades, not years. The robust operating temperature range further ensures performance stability in environments where temperature is not consistently controlled, a common scenario in manufacturing and logistics.
Frequently Asked Questions (FAQ)
Technical Clarifications for Design Engineers
What does the 50,000-hour MTTF of the CCFL backlight practically mean for my application?
This metric indicates that the backlight is engineered for a very long operational life, equivalent to nearly six years of continuous 24/7 operation before reaching its half-life luminance. This minimizes the frequency of maintenance cycles and enhances the overall reliability of the final product.
How does the -10 to 70°C operating temperature range impact system design?
This wide range allows the display to be integrated into non-climate-controlled environments, such as factory floors, warehouses, or outdoor-facing enclosures. It reduces the need for complex and costly thermal management systems like active cooling or heating, thereby simplifying the overall mechanical design and lowering power consumption.
Is the Parallel RGB interface difficult to integrate with modern controllers?
While many modern systems use LVDS or eDP, the Parallel RGB interface is a well-documented, standard interface that is still directly supported by numerous industrial single-board computers and microcontrollers. Its simplicity can be an advantage, avoiding the signal integrity complexities of higher-speed serial interfaces and potentially reducing development time for certain system architectures.
What is the significance of the 12 o'clock viewing direction?
This specifies the optimal viewing angle is from above the screen, which is a critical consideration for ergonomics and usability. For equipment where the operator is typically standing and looking down at a control panel, a 12 o'clock viewing angle ensures the best image quality, contrast, and color fidelity.
Can the backlight be replaced in the field?
Yes, the datasheet explicitly mentions a "Replaceable structure of lamp unit." This is a significant feature for industrial applications, as it enables trained technicians to service the display on-site, drastically reducing downtime and the total cost of ownership compared to displays that require factory refurbishment or complete replacement.
Technical Deep Dive
A Closer Look at Serviceability and Thermal Resilience
The engineering philosophy behind the LTA084A380F prioritizes operational longevity over cutting-edge display metrics. The two most critical design choices supporting this are the replaceable CCFL backlight and the extended temperature range. The choice of a CCFL backlight with a user-serviceable design is a deliberate trade-off. While modern LED backlights offer higher efficiency, the field-replaceable nature of this CCFL unit is a decisive advantage in legacy systems and long-lifecycle equipment. This is analogous to designing a machine with modular, field-replaceable parts versus a sealed, disposable unit; for industrial capital equipment, serviceability is a non-negotiable requirement. Furthermore, the ability to operate reliably up to 70°C is a testament to the thermal robustness of the a-Si TFT panel and its driving electronics, ensuring image stability and preventing premature aging in thermally challenging enclosures often found in industrial automation and control systems.
Engineer's Perspective on System Integration
From an integration standpoint, the LTA084A380F represents a low-risk, stable solution for established industrial platforms. Its standard VGA resolution and parallel interface ensure backward compatibility and straightforward implementation with a wide array of existing controllers. The key design consideration is not chasing the highest resolution or widest color gamut, but ensuring the display will remain operational and maintainable for the decade-plus service life expected of the host equipment. This panel is engineered for the realities of the factory floor, not the conference room.
