## M150XN06 V3: Industrial 15.0-inch XGA TFT-LCD for Robust HMI Systems
The AUO M150XN06 V3 is a 15.0-inch XGA TFT-LCD module specifically engineered for consistent performance and reliability in challenging industrial environments. This display delivers a precise **1024x768 XGA** resolution through a standard **LVDS interface**, ensuring both high-quality image reproduction and straightforward system integration. Key benefits include a durable anti-glare surface for enhanced readability and robust construction for operational longevity. Designed with standard interfaces and proven optical characteristics, this display simplifies integration into industrial control panels and embedded systems. For industrial HMIs requiring proven XGA resolution with reliable wide-temperature operation, the M150XN06 V3 is a technically sound choice.
Key Parameter Overview
Decoding the Specs for Industrial Reliability
The technical specifications of the M150XN06 V3 are tailored for integration into systems where durability and consistent visual performance are paramount. The combination of its resolution, interface, and physical design provides a stable platform for a wide range of industrial and commercial applications.
| Parameter | Specification |
|---|---|
| Manufacturer | AUO |
| Screen Size | 15.0 inches |
| Resolution | 1024(RGB)×768, XGA |
| Display Technology | a-Si TFT-LCD, TN, Normally White |
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 400:1 (Typ.) |
| Viewing Angle | 60/60/40/50 (Typ.)(CR≥10) (L/R/U/D) |
| Interface Type | LVDS (1 ch, 6/8-bit), 20 pins Connector |
| Power Supply Voltage | 3.3V (Typ.) |
| Surface Treatment | Antiglare, Hard coating (3H) |
| Operating Temperature | 0 ~ 60 °C |
| Storage Temperature | -20 ~ 60 °C |
Note: The parameters listed above are based on aggregated reference data. For complete specifications, performance curves, and mechanical drawings, it is essential to consult the official product datasheet.
Download the M150XN06 V3 datasheet for detailed specifications and performance curves.
Application Scenarios & Value
Delivering System-Level Benefits in Industrial and Commercial Displays
The M150XN06 V3 is engineered to address common challenges in the design of Human-Machine Interfaces (HMIs) and specialized information displays. Its feature set provides tangible value in environments where off-the-shelf consumer displays would fall short.
A primary application is in industrial automation, integrated into control panels for manufacturing equipment. In a factory setting, ambient lighting from overhead fixtures can cause significant glare, making it difficult for operators to monitor critical process data on a standard screen. The M150XN06 V3's **anti-glare surface treatment** diffuses these reflections, ensuring that key metrics and alerts are always legible. This directly contributes to reduced operator error and improved plant safety. The standard **LVDS** interface further streamlines the design process, allowing engineers to easily connect the panel to a wide array of single-board computers (SBCs) or dedicated display controllers common in the **industrial automation** sector.
The display's contrast ratio and **1024x768 XGA** resolution provide the necessary clarity for detailed graphical user interfaces, such as those used in point-of-sale (POS) systems, medical information displays, and test and measurement equipment. The balance of performance and durability makes it a reliable choice for long-lifecycle products. For systems requiring a similar form factor but with different optical characteristics, the G150XNE-L01 may offer alternative performance points for consideration.
Frequently Asked Questions (FAQ)
What is the primary advantage of the anti-glare (AG) surface treatment in an industrial setting?
The anti-glare surface on the M150XN06 V3 is crucial for maintaining screen legibility in environments with high ambient light, such as factory floors or brightly lit commercial spaces. It scatters reflections that would otherwise obscure the display, ensuring that operators can read critical information clearly and without eye strain, which is vital for both productivity and safety.
How does the LVDS interface simplify the design of a custom HMI or embedded system?
The Low-Voltage Differential Signaling (LVDS) interface is a widely adopted standard for internal display connections. Its presence on the M150XN06 V3 means that engineers can use readily available cables and connectors, and it is natively supported by a vast number of industrial motherboards and single-board computers. This simplifies electrical design, reduces development time, and helps control system costs.
Is the 0 to 60°C operating temperature range suitable for outdoor applications?
The specified operating range is ideal for indoor industrial and commercial environments, including factory floors, control rooms, and retail settings where ambient temperatures are generally controlled. For direct outdoor deployment exposed to sunlight and extreme weather, a display with a wider operating temperature range (e.g., -20°C or lower to +70°C or higher) and higher brightness would be required. This model is best suited for protected or indoor locations.
Strategic Importance in System Design
Building Reliable Systems with Proven Display Technology
Opting for an industrial-grade panel like the M150XN06 V3 is a strategic decision that prioritizes long-term system reliability and a stable supply chain over the lower initial cost of consumer-grade alternatives. The robust construction and industry-standard interface are foundational elements for building equipment that performs consistently over its intended service life. By integrating components designed for the rigors of industrial and commercial use, engineers can reduce the total cost of ownership, minimize field failures, and enhance brand reputation. For designers of next-generation HMIs and embedded visual systems, leveraging established and reliable display technology like that found in the M150XN06 V3 remains a cornerstone of successful product development.
