#Powerex, #PM15CSJ060, #IGBT_Module, #IGBT, Intellimod™ Module Three Phase IGBT Inverter Output 15 Amperes/ 600 Volts
PM15CSJ060 Description This three phase IGBT inverter output module weighs 0.13 lbs. with a collector current amount of 15A and a collector emitter of 600V.One of best things you can get from PM15CSJ060 is its unique built-in control circuits that allow the power module to create its own protection system. This defense system includes reliable shields against short circuit, over current, over temperature, under voltage, or any electrical malfunctions.Other special features of PM15CSJ060 are its “Complete Output Power Circuit” and “Gate Drive Circuit,” which both serve as enhancement force in transcending the power and drive capacity of UPS. Indeed, these unique abilities have led PM15CSJ060 to become a standout intelligent power module these days. Absolute Maximum Ratings, Tj = 25°C unless otherwise specified Power Device Junction Temperature Tj -20 to 150°C Storage TemperatureTstg -40 to 125°C Case Operating Temperature TC -20 to 100°C Mounting Torque, M4 Mounting Screws 13 in-lb Module Weight (Typical) 60 Grams Supply Voltage Protected by OC and SC (VD = 13.5 - 16.5V, Inverter Part) VCC(prot.) 400 Volts Isolation Voltage, AC 1 minute, 60Hz VRMS 2500 Volts Collector-Emitter Voltage (VD = 15V, VCIN = 15V) VCES 600 Volts Collector Current,IC ± 15 Amperes Peak Collector Current,ICP ± 30 Amperes Supply Voltage (Applied between P - N) VCC 450 Volts Supply Voltage, Surge (Applied between P - N) VCC (surge) 500 Volts Collector Dissipation PC 43 Watts
