Features
●Heat transfer through aluminium oxide ceramic isolated metal baseplate
●Hard soldered joints for high reliability
Typical Applications*
●Non-controllable rectifers for AC/IAC converters
●Line rectifiers for transistorized AC motor controllers
●Field supply for DC motors
●Free-wheeling diodes
.Absolute maximum ratings (Tc=25°C unless without specified)
Collector-Emitter voltage Vces:1200V
Gate-Emitter voltage VGES:±20V
Collector current Ic Continuous Tc=25°C :82A
Collector current Icp 1ms Tc=25°C :175A
Collector power dissipation Pc:400W
Isolation Voltage VIsol (AC 1 minute) :3600V
Operating junction temperature Tj:+150°C
Storage temperature Tstg :-40 to +125°C
Mass 95g
