Optrex DMF-50174ZNB-FW LCD Display

Kyocera DMF-50174ZNB-FW: 240x64 STN display with high-contrast negative mode & integrated LED backlight, delivering robust clarity for demanding industrial & medical HMIs.

· Categories: LCD Display
· Manufacturer: Optrex
· Price: US$
· Date Code: 2024+
. Available Qty: 279
Like
Tweet
Pin It
4k
Email: sales@shunlongwei.com
Whatsapp: 0086 189 2465 1869

Contact us To Buy Now!

DMF-50174ZNB-FW Specification

Optrex DMF-50174ZNB-FW | High-Clarity 240x64 STN Graphical Display

The Optrex **DMF-50174ZNB-FW** is a purpose-built monochrome graphical LCD module engineered for applications where data legibility and operational robustness are non-negotiable. It delivers a crisp 240x64 resolution, providing an ideal canvas for complex user interfaces that blend text, icons, and simple charts. This display is not just a component; it's a solution for creating clear, reliable human-machine interfaces (HMIs) in demanding industrial, medical, and test equipment environments.

Unpacking the Visual Performance: A Technical Deep Dive

Understanding the technology inside the **DMF-50174ZNB-FW** reveals why it excels in its target applications. Two core features stand out:

  • STN Negative Blue Mode Display

    Technical Principle: This module utilizes Super-Twisted Nematic (STN) liquid crystal technology in a negative image mode. This results in bright pixels on a dark blue/black background, a format known for its exceptionally high contrast ratio and perceived sharpness. Unlike power-hungry color TFTs, STN technology is remarkably power-efficient.

    Application Value: For an operator on a factory floor or a technician reading a measurement device, this translates to immediate and unambiguous readability, even from a distance or at an angle. The high contrast reduces eye strain and minimizes the chance of misinterpreting critical data, directly enhancing operational safety and accuracy.

  • Integrated White LED Backlight

    Technical Principle: The module comes equipped with a built-in, long-life white LED backlight system. This integrated design simplifies the engineering process by eliminating the need for a separate, complex high-voltage inverter circuit that older CCFL backlights required.

    Application Value: This integration directly reduces your bill of materials (BOM) cost and design complexity. Your engineering team can focus on the core application logic instead of designing and troubleshooting backlight driver circuits. The result is a faster time-to-market and a more reliable end product with a lower total cost of ownership. For our full range of display solutions, explore our industrial LCDs.

Where the DMF-50174ZNB-FW Excels: Application-Specific Value

This display's unique characteristics make it a superior choice for several key sectors:

  • Industrial Control Panels: The wide 240x64 format is perfect for displaying multiple lines of status alerts, machine parameters, and soft-key menu labels simultaneously, providing a comprehensive overview of system status.
  • Test and Measurement Instruments: In devices like network analyzers or power meters, the graphical capability allows for rendering simple waveforms, bar graphs, and detailed measurement data with precision and clarity.
  • Medical Equipment: For patient monitoring systems, infusion pumps, or diagnostic devices, the **DMF-50174ZNB-FW** offers the reliable, high-contrast display needed for critical health information, ensuring legibility in varied hospital lighting conditions.
  • Legacy System Retrofits: Its standard 8-bit parallel interface and common form factor make it an excellent drop-in replacement for aging or discontinued displays, extending the life of valuable equipment without a complete system redesign.

Critical Specifications at a Glance

ParameterValue
ManufacturerKyocera (formerly Optrex)
Part NumberDMF-50174ZNB-FW
Display TechnologySTN (Super-Twisted Nematic), Negative, Transmissive
Resolution240 x 64 Dots
BacklightWhite LED
Interface8-bit Parallel
Operating Temperature-20°C to +70°C
Outline Dimensions180.0(W) x 65.0(H) x 12.1(D) mm

Navigating Your Display Choices: DMF-50174ZNB-FW vs. Alternatives

When selecting a display, it's crucial to match the technology to the task.

  • vs. Full-Color TFT: While color TFTs are ideal for rich media, they introduce higher power consumption, greater software complexity, and potential wash-out in direct light. The DMF-50174ZNB-FW is the superior choice for applications where the primary goal is presenting critical data with maximum clarity, reliability, and power efficiency.
  • vs. Character LCDs: Standard character modules are simple but restrictive. The graphical nature of the DMF-50174ZNB-FW provides design freedom, allowing for custom fonts, international character sets, company logos, and dynamic icons, creating a more sophisticated and user-friendly product.

For systems that demand a robust, clear, and efficient graphical interface without the overhead of a full-color display, the Optrex **DMF-50174ZNB-FW** presents a compelling and field-proven solution. If your project requires this specific blend of performance and industrial-grade reliability, please contact us for a quote to discuss your application's unique requirements.
