The Innolux LCD panel with the model number NG121XCE-L01:
- General Information:
- Brand: Innolux
- Model: NG121XCE-L01
- Diagonal Size: 12.1 inch
- Panel Type: a-Si TFT-LCD, LCM
- Resolution: 1024(RGB)×768, XGA, 105PPI
- Pixel Format: RGB Vertical Stripe
- Active Area: 245.76(W)×184.32(H) mm
- Bezel Opening: 249.0(W)×187.5(H) mm
- Outline Dimensions: 260.5(H)×204(V)×8.9(D) mm
- Treatment: Antiglare, Hard coating (3H)
- Display Characteristics:
- Luminance: 600 cd/m² (Typ.)
- Contrast Ratio: 1000:1 (Typ.) (TM)
- Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
- Response Time: 13/12 (Typ.)(Tr/Td) ms
- View Direction: Symmetry
- Operating Mode: AAS, Normally Black, Transmissive
- Support Color: 262K/16.7M, 72% NTSC
- Backlight, Weight, and Design:
- Light Source: WLED, 50K hours, With LED Driver
- Weight: 490/510g (Typ./Max.)
- Designed For: Industrial
- Frame Rate and Touch Panel:
- Frame Rate: 60Hz
- Touch Panel: Without
- Interface Type and Power Supply:
- Interface Type: LVDS (1 ch, 6/8-bit), 20 pins Connector
- Power Supply: 3.3V (Typ.)
- Operating Environment:
- Operating Temperature: -30 ~ 85 °C
- Storage Temperature: -40 ~ 90 °C
