G150XTN05.0 | 15.0" XGA LCD Module for High-Reliability Industrial HMIs
An Engineering-Focused Overview of the AUO G150XTN05.0
Content last revised on October 17, 2025.
The AUO G150XTN05.0 is a 15.0-inch XGA display engineered for long-term reliability and visual performance in demanding thermal environments. Featuring a classic 4:3 aspect ratio, this a-Si TFT-LCD panel delivers the essential performance for a new generation of robust industrial equipment. Key specifications include: 1024x768 XGA | 450 cd/m² Brightness | -30°C to +70°C Operating Range. This module provides enhanced system robustness and enables a simplified integration design. What is the key benefit of the G150XTN05.0's wide temperature range? Reliable operation from -30°C to 70°C without auxiliary heating or cooling. With its expansive operating temperature range, this module is the optimal choice for unconditioned industrial HMIs that demand consistent performance.
Key Parameter Overview
Decoding the Specifications for Operation in Extreme Climates
The performance metrics of the G150XTN05.0 are tailored for industrial applications where environmental conditions are a primary design consideration. The specifications below highlight its capability to deliver stable optical performance across a wide operational spectrum.
| Feature | Specification | Engineering Value |
| Screen Diagonal | 15.0 inch | Standard industrial size for clear data visualization in control panels and kiosks. |
| Resolution | 1024(RGB)×768, XGA | Provides sharp, detailed imaging suitable for complex graphical interfaces. |
| Luminance | 450 cd/m² (Typ.) | Ensures screen readability in varied indoor and sheltered outdoor lighting conditions. |
| Contrast Ratio | 800:1 (Typ.) | Delivers deep blacks and vibrant colors for improved image clarity and operator focus. |
| Operating Temperature | -30 ~ 70 °C | Critical for deployment in harsh thermal environments, from cold storage to sun-exposed enclosures. |
| Interface Type | LVDS (1 ch, 6/8-bit), 20 pins Connector | A robust and widely adopted interface for reliable data transmission in industrial systems. |
| Backlight | WLED, 50K hours, With LED Driver | Long-life backlight with an integrated driver simplifies design and enhances system reliability. |
| Surface Treatment | Anti-Glare, Hard coating (3H) | Minimizes distracting reflections and provides durability against incidental contact. |
Download the G150XTN05.0 datasheet for detailed specifications and performance curves.
Application Scenarios & Value
System-Level Benefits in Demanding Industrial and Outdoor HMIs
The G150XTN05.0 is engineered specifically for applications where standard consumer-grade displays would fail. Its core value lies in its environmental resilience, making it a strategic choice for system integrators developing equipment for challenging settings.
- Industrial Automation: In factory floor Human-Machine Interface (HMI) panels and next to CNC machinery, the -30°C to +70°C operating range ensures flawless startup and operation, irrespective of ambient factory temperatures. The anti-glare surface is critical for reducing errors caused by reflections from overhead lighting.
- Outdoor Kiosks and Ticketing Systems: For sheltered outdoor applications like ticketing machines or information kiosks, the display's ability to function in sub-zero and high-heat conditions reduces the need for complex and costly environmental control systems within the enclosure.
- Vehicle-Mounted Terminals: Deployed in logistics, agriculture, or construction vehicles, the G150XTN05.0's specifications for shock and vibration, combined with its wide temperature tolerance, ensure operational uptime and display longevity in mobile, high-stress environments.
The integration of the LED driver onto the module is a significant design advantage. This simplifies the connection to an Industrial PC (IPC) or single-board computer, reducing the internal component count, minimizing potential points of failure, and streamlining the overall assembly process. While the G150XTN05.0 provides excellent performance for direct-view HMIs, systems requiring superior off-axis readability for multiple viewers might consider the AHVA technology in the G150XNE-L01.
FAQ
Engineering Questions on Integration and Long-Term Reliability
What makes the G150XTN05.0 suitable for outdoor-facing applications?
Its suitability stems from a combination of three key features: the exceptionally broad operating temperature range (-30°C to 70°C) ensures functionality in most climates, the 450-nit brightness provides solid readability in shaded or indirect sunlight, and the anti-glare surface treatment diffuses reflections to maintain clarity.
How does the integrated LED driver simplify the system design process?
An integrated LED driver streamlines design by eliminating the need to source, qualify, and integrate a separate driver board. This reduces the bill of materials (BOM), simplifies the power delivery architecture, requires fewer internal cables, and can help mitigate electromagnetic interference (EMI) challenges, leading to a faster and more robust design cycle.
Application Vignette
Designing a Reliable Operator Control Panel for Unconditioned Warehouse Logistics
An engineering team is tasked with developing a forklift-mounted terminal for a large distribution center where loading docks are exposed to external weather conditions. The primary challenge is ensuring the HMI is operational 24/7, from freezing pre-dawn shifts to hot summer afternoons, while withstanding the constant vibration of the vehicle.
By selecting the G150XTN05.0, the team directly addresses these core challenges. The panel's ability to operate down to -30°C eliminates the need for an internal heater component and its associated power draw and control circuitry. This is a critical advantage; choosing a display with a wide native temperature range is like using an all-weather tire rated for severe snow service on a vehicle. It's designed from the material level up for the conditions, preventing sluggish response or physical damage, unlike a standard component that would require external aids to survive.
Furthermore, the built-in WLED backlight system and driver are specified for a 50,000-hour lifetime, contributing to a lower total cost of ownership by extending the service interval of the terminal. The single-unit design of the display with its integrated driver simplifies the mechanical assembly inside the ruggedized enclosure and reduces the number of interconnects—a common source of failure in high-vibration settings. The result is a more reliable, cost-effective, and easily serviceable HMI terminal built for the realities of the logistics industry.
For engineers designing systems with similar environmental demands, the G150XTN05.0 from manufacturer AUO offers a proven platform. A detailed review of the datasheet is recommended to validate its performance against your specific application requirements.
