Toshiba LTM06C310 | Proven VGA Display for Mission-Critical Industrial & Medical Systems
The Toshiba LTM06C310 is a testament to engineering that prioritizes reliability and longevity over fleeting trends. This 6.4-inch VGA TFT-LCD was designed as a workhorse for applications where consistency, compatibility, and a long service life are non-negotiable. It remains a critical component for maintaining and servicing a vast installed base of high-value industrial and medical equipment, providing a form-fit-function replacement that avoids costly system redesigns.
Product Highlights for the Engineering Professional
- Proven Industrial & Medical Grade: Built for stability and long-term performance in demanding environments.
- Standard 6.4" VGA Format: The 640x480 resolution is a perfect match for legacy Human-Machine Interfaces (HMIs), control panels, and test equipment.
- High-Reliability CCFL Backlight: Offers a stable color spectrum and a well-understood, predictable aging process ideal for scheduled maintenance cycles.
- Direct Parallel RGB Interface: Ensures straightforward integration with a wide range of embedded controllers and single-board computers, simplifying repair and replacement tasks.
Key Technical Specifications
For engineers requiring a quick data review, the core performance metrics of the Toshiba LTM06C310 are outlined below. These parameters highlight its suitability for clear, effective information display in controlled environments. For complete electrical and mechanical details, you can Download the LTM06C310 Datasheet.
| Parameter | Specification |
|---|---|
| Screen Size | 6.4 inches |
| Resolution | 640(RGB)×480 [VGA] |
| Display Technology | a-Si TFT-LCD, Normally White |
| Luminance | 200 cd/m² (Typ.) |
| Contrast Ratio | 300:1 (Typ.) |
| Backlight System | Single CCFL with an estimated 50K-hour lifetime |
| Interface Type | Parallel RGB (1 ch, 6-bit) |
| Operating Temperature | 0 ~ 50 °C |
Engineered for Legacy System Continuity
The design choices behind the LTM06C310 are rooted in practical, long-term application needs. Its a-Si TFT (Amorphous Silicon) technology is a mature and highly stable platform, delivering consistent image quality without the risk of burn-in often associated with other technologies in static display scenarios. This makes it an ideal choice for control interfaces where elements may remain on-screen for extended periods.
While modern displays have shifted to LED backlighting, the CCFL system in the Toshiba LTM06C310 provides a key advantage for legacy equipment: predictability. The gradual dimming of a CCFL over its 50,000-hour lifespan is a known quantity, allowing for proactive maintenance rather than abrupt failure. This is a critical feature in medical and industrial fields where unexpected downtime is unacceptable. The display's standard parallel interface further solidifies its role as a drop-in replacement, eliminating the need for complex interface conversion hardware or software redevelopment.
Application Scenarios & Value Manifestation
The LTM06C310 delivers tangible value in several key sectors:
- Medical Patient Monitoring: In bedside monitors and diagnostic machines, the display's stable color reproduction and reliable performance ensure that vital signs and data are presented clearly and consistently, year after year.
- Industrial HMI Panels: For CNC machines, process controllers, and factory automation systems, this display serves as a vital replacement part, keeping established and validated production lines running smoothly. Its straightforward integration minimizes downtime during repairs.
- Test and Measurement Equipment: Legacy oscilloscopes, spectrum analyzers, and other instruments rely on this exact form factor and resolution. The LTM06C310 allows for the repair of this high-value equipment, extending its operational life significantly.
For a deeper understanding of the technologies that power modern displays, you can explore our ultimate guide to TFT LCDs. If your equipment requires a specific interface or you are unsure about compatibility, please contact our technical team for expert guidance.
