Content last revised on February 14, 2025
Brand Sharp
Model LM64K83
Diagonal Size 9.4 inch
Type FSTN-LCD , LCM
Pixel Format 640×480 [VGA] 84PPI
Configuration Rectangle
Active Area 191.97(H)×143.97(V) mm
Outline Dim. 253(H)×174(V) mm
Bezel Area 201.4(H)×153.4(V) mm
Luminance 45 cd/m² (Typ.)
Contrast Ratio 10:1 (Typ.) (TM) 8:1 (Typ.) (RF)
Response Time 100/150 (Typ.)(Tr/Td)
Viewing Angle 35/25/30/25 (Typ.)(CR≥2) Left / Right / Up / Down
Operating Mode STN, Black/White (Positive), Transflective
IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich
VA Family: ASV, HVA, MVA, PVA, SVA, UV²A, VA
Support Color Monochrome
Light Source CCFL [1 pcs] , W/O Driver
Weight 340g (Typ.)
Designed For Industrial
Touch Panel Without
Interface Type Parallel Data (4-bit) , 15 pins Connector
Power Supply 5.0V (Typ.)
Environment Operating Temperature: 0 ~ 45 °C ; Storage Temperature: -25 ~ 60 °C
