Panel Brand:
Toshiba Panel Model: LTM08C355S
Panel Size: 8.4"
Panel Type: LTPS TFT-LCD, LCM
Resolution: 800(RGB)×600 , SVGA
Pixel Format: RGB Vertical Stripe
Display Area: 170.4(W)×127.8(H) mm
Bezel Opening: 173.4(W)×130.8(H) mm
Outline Size: 200.3(W)×140.3(H) ×5.5(D) mm
Brightness: 145 cd/m² (Typ.)
Contrast Ratio: 250:1 (Typ.) (TM)
Display Mode:TN, Normally White, Transmissive
Response Time: 50/50 (Max.)(Tr/Td)
Display Colors: 262K
Lamp Type: 1 pcs CCFL , Without Driver
Frequency: 60Hz
Touch Screen: Without
Signal Interface: Parallel RGB (1 ch, 6-bit) , 30 pins , Connector
Input Voltage: 3.3V (Typ.)(VDD)
Environment: Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
LTM08C355S inverter, LTM08C355S power supply, LTM08C355S electronic board, LTM08C355S VGA board, LTM08C355S touchscreen available.
