Semikron SKM300GA12E4 IGBT Module

Features*

●High speed trench and field-stop IGBT

●CAL4 ultra-fast = soft switching 4. generation CAL-diode

●Insulated copper baseplate using DBC technology (Direct Bonded Copper)

●Increased power cycling capability

●For higher switching frequencies above 15kHz

Typical Applications

●UPS

●Electronic welders

●Inductive heating

●Switched mode power supplies

Remarks

●Case temperature limited to Tc= 125°C max.

●Recommended Top = -40... +150°C

●Product relibility results valid for Tj= 150°C

Absolute maximum ratings (Tc=25°C unless without specified)

Collector-Emitter voltage Vces:1200V

Gate-Emitter voltage VGES:±20V

Collector current Ic Continuous Tc=25°C :400A

Collector current Icp 1ms Tc=25°C :800A

Collector power dissipation Pc:140W

Isolation Voltage VIsol (AC 1 minute) :4000V

Operating junction temperature Tj:+150°C

Storage temperature Tstg :-40 to +125°C

Mounting screw torque 2.5~5 N·m

Weight 325 g
