Content last revised on January 29, 2026
TX26D22VM0APA JDI 10.4-inch SVGA High-Brightness Industrial LCD Display
The TX26D22VM0APA, manufactured by JDI (Japan Display Inc.) and distributed through its industrial subsidiary KOE, is a high-performance 10.4-inch TFT LCD designed specifically for demanding outdoor and industrial environments. This module stands out by integrating an IPS (In-Plane Switching) panel with an exceptional 1200 cd/m² brightness rating, ensuring vivid color reproduction and superior sunlight readability. For engineering teams prioritizing visibility in high-ambient light conditions without compromising thermal stability, the TX26D22VM0APA provides a robust, long-lifecycle solution.
What is the primary benefit of its high-brightness LED backlight? It ensures exceptional readability in direct sunlight while maintaining a 70,000-hour operational life. For outdoor HMI applications requiring SVGA resolution and extreme temperature resilience, this 10.4-inch display is the optimal choice.
Key Parameter Overview
Decoding the Specs for Enhanced Industrial Reliability
The following technical specifications define the TX26D22VM0APA performance envelope. These values are derived from the official manufacturer documentation to support precise system integration and thermal budgeting.
| Feature | Specification Details |
|---|---|
| Manufacturer | JDI / KOE |
| Screen Size | 10.4-inch (Diagonal) |
| Resolution | 800 x 600 (SVGA) |
| Brightness | 1200 cd/m² (Sunlight Readable) |
| Contrast Ratio | 1200:1 |
| Viewing Angle | 85/85/85/85 (IPS Technology) |
| Interface | 20-pin LVDS (1-ch, 6/8-bit) |
| Operating Temp | -30°C to +80°C |
| Backlight Life | 70,000 Hours (LED) |
Application Scenarios & Value
Achieving System-Level Benefits in High-Ambient Environments
The TX26D22VM0APA is engineered to solve the visibility challenges inherent in outdoor human-machine interfaces. By combining 1200 nits of luminance with a high 1200:1 contrast ratio, it minimizes the "washout" effect typical of standard industrial panels. This makes it a critical component for marine navigation systems, electric vehicle (EV) charging stations, and heavy machinery instrumentation.
Consider the challenge of designing an outdoor kiosk located in a region with high solar load. A standard 350-nit display would require significant shading or active cooling to prevent isotropic failure under sun exposure. The TX26D22VM0APA addresses this with an wide -30°C to +80°C operating range, allowing the display to maintain liquid crystal integrity even when internal enclosure temperatures rise. Furthermore, its IPS technology ensures that operators can view critical data from any angle (up to 170 degrees horizontally and vertically) without the color inversion common in TN panels.
For systems requiring similar dimensions but different technical trade-offs, engineers may also evaluate the G104VN01 V0 or the G104XCE-L01 for specific resolution or interface requirements.
Technical Deep Dive
Advanced Backlight and IPS Architecture for Long-Term Performance
The technical excellence of the TX26D22VM0APA lies in its thermal management of the LED backlight. Driving a backlight to 1200 cd/m² generates significant heat; JDI utilizes high-efficiency LED strings and an optimized thermal path to dissipate this heat effectively, preventing localized "hot spots" that could degrade the TFT-LCD layer. This efficiency is why the module achieves a 70,000-hour half-life, a benchmark for industrial-grade longevity.
The IPS (In-Plane Switching) technology used in this 10.4-inch panel is also vital for high-accuracy applications like medical imaging or precision agriculture. Unlike standard displays where the color shifts based on the viewer's height, the TX26D22VM0APA maintains chromatic consistency. To understand more about how these panel technologies influence efficiency, engineers can explore our guide on TFT-LCD industrial applications.
Industry Insights & Strategic Advantage
Meeting the Demand for All-Weather Digital Signage and HMI
The shift toward "Outdoor Everything" in the industrial sector—from digital ticketing to remote infrastructure monitoring—has placed a premium on panels that can survive the elements. The TX26D22VM0APA reflects the industry trend toward sunlight-readable HMIs that prioritize Total Cost of Ownership (TCO). While consumer-grade displays might offer lower initial costs, their failure rates in extreme temperatures lead to expensive field maintenance.
By specifying a display with an integrated LVDS interface and high-brightness specs, manufacturers can simplify their supply chain and enclosure design. The TX26D22VM0APA ensures compliance with the ruggedness requirements found in heavy machinery displays, where vibration and temperature cycling are constant threats to system uptime.
FAQ
How does the 1200 cd/m² brightness of the TX26D22VM0APA impact power consumption and thermal design?
High brightness requires higher current to the LED driver. Engineers must ensure the 20-pin LVDS system and the backlight power rail can handle the required wattage. Proper ventilation is recommended to maintain the panel within its 80°C maximum operating limit during peak solar exposure.
What is the primary benefit of using IPS technology in an outdoor 10.4-inch display?
IPS eliminates color shifting and provides 170-degree viewing angles. This is crucial for equipment where the operator may be viewing the TX26D22VM0APA from an off-center position, such as in a cockpit or a large industrial control room.
Can the TX26D22VM0APA operate in sub-zero environments without an integrated heater?
Yes, it is rated down to -30°C. The liquid crystal material used by JDI is formulated to remain responsive at these temperatures, ensuring that on-screen animations or data updates do not suffer from excessive "ghosting" in cold climates.
Is the LVDS interface compatible with standard industrial single-board computers (SBCs)?
The TX26D22VM0APA uses a standard 1-channel LVDS interface, making it broadly compatible with most industrial ARM and x86-based SBCs. Its SVGA (800x600) resolution is a legacy-friendly format that integrates easily with existing HMI software frameworks.
In an era where digital clarity is non-negotiable for safety and operational efficiency, the TX26D22VM0APA represents a strategic investment for OEMs. Its combination of high-luminance output, IPS color accuracy, and wide-temperature resilience ensures it remains a reliable interface for the most demanding global environments. For technical teams, selecting this JDI module means prioritizing field-proven performance over short-term savings.
