Samsung LTM170E8-L03 | Robust 17.0" SXGA Display for Critical Industrial & Medical Systems
The Samsung LTM170E8-L03 is a 17.0-inch a-Si TFT-LCD panel engineered for longevity and visual consistency in demanding environments. It serves as a vital component for maintaining and upgrading legacy systems where reliability and a specific 5:4 aspect ratio are non-negotiable. This display is an ideal solution for system integrators and MRO (Maintenance, Repair, and Operations) engineers focused on extending the life of critical infrastructure.
Key Engineering Highlights
- Classic SXGA Resolution: The 1280 x 1024 resolution and 5:4 aspect ratio are perfectly suited for legacy industrial HMI, process control, and medical imaging applications that were designed around this traditional format.
- Exceptional Viewing Angles: With symmetrical 80/80/80/80 viewing angles, the LTM170E8-L03 ensures image clarity and color fidelity from virtually any perspective, a critical feature for multi-operator stations or complex machinery panels.
- High Contrast & Color Fidelity: An 800:1 contrast ratio and 72% NTSC color gamut deliver sharp, vibrant, and easily distinguishable visuals, crucial for interpreting complex data or detailed graphical interfaces.
- Proven CCFL Backlight System: Equipped with a robust 4-lamp CCFL backlight and an integrated inverter, this panel provides 300 nits of brightness, ensuring dependable performance as a drop-in replacement for systems originally designed with this technology.
Core Technical Specifications
For engineers requiring precise data for system integration or replacement validation, the key parameters of the Samsung LTM170E8-L03 are outlined below. For a comprehensive list of specifications, you can Download the LTM170E8-L03 Datasheet.
| Parameter | Specification |
|---|---|
| Screen Size | 17.0 inches |
| Resolution | 1280 (RGB) x 1024 [SXGA] |
| Panel Technology | a-Si TFT (Amorphous Silicon), Normally White |
| Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) |
| Viewing Angle (L/R/U/D) | 80/80/80/80 (Typ.) |
| Response Time | 8 ms (Typ.) |
| Signal Interface | LVDS Interface (2 ch, 8-bit) |
| Backlight System | 4 pcs CCFL with Inverter |
| Operating Temperature | 0°C to 50°C |
Application Scenarios & Engineering Value
The LTM170E8-L03 is not just a component; it's a solution for maintaining operational continuity. Its unique features deliver tangible value in specific applications:
- Industrial Automation & Control Panels: The SXGA resolution is the native format for countless legacy HMI programs. Using this display avoids costly software redevelopment and UI redesign, making it a plug-and-play solution for replacing failed units in CNC machines, PLCs, and manufacturing execution systems.
- Medical Diagnostic Equipment: In fields like ultrasound and endoscopy, consistent color and a high Contrast Ratio are critical for accurate diagnosis. The wide viewing angles allow multiple clinicians to view the screen simultaneously without color shift or distortion.
- Air Traffic Control & Marine Systems: While not designed for direct sunlight, this panel is a workhorse for indoor or bridge applications. Its robust build and standard LVDS interface ensure compatibility with a wide range of established ATC and navigation systems that rely on the 5:4 form factor for displaying critical flight or vessel data.
Strategic Advantage for Long-Term System Support
In an industry rapidly moving towards widescreen formats, the Samsung LTM170E8-L03 provides a critical strategic advantage: lifecycle extension. The cost of recertifying an entire medical device or re-tooling a manufacturing line often far exceeds the cost of a replacement display. By providing a form, fit, and function replacement for older panels, this display protects significant capital investment and minimizes operational downtime. It represents a commitment to supporting the extensive installed base of high-value industrial and medical equipment, ensuring they remain productive for years to come. If you're managing legacy systems, sourcing reliable industrial LCD displays like this is a cornerstone of a sound maintenance strategy.
Frequently Asked Questions (FAQ)
Q: The LTM170E8-L03 uses a CCFL backlight. What are the implications for my application?
A: The CCFL backlight is a key feature for backward compatibility. Many legacy systems were designed with driver boards and power supplies specifically for CCFL inverters. Using an LED-backlit panel would require an additional LED driver and potentially complex signal conversion. The LTM170E8-L03's integrated CCFL system simplifies the replacement process, ensuring a seamless electrical and mechanical fit without re-engineering.
Q: Is the SXGA (1280x1024) format still relevant?
A: Absolutely. For millions of deployed systems, the HMI software, graphical elements, and physical console cutouts are built around the 5:4 aspect ratio of SXGA. Replacing a failed display with a widescreen panel would result in stretched, distorted, or cropped visuals, which is unacceptable for precise control or diagnostic applications. This makes the SXGA format essential for MRO and system support. For a deeper understanding of the core technology, explore our guide to TFT-LCDs.
For questions about compatibility, volume pricing, or to verify if the LTM170E8-L03 is the right fit for your system upgrade, please contact our technical team for expert consultation.
